GREEN GLUE NOISEPROOFING COMPOUND (TUBES / PAILS)

Green Glue Noiseproofing Compound is a viscoelastic damping compound that is used between layers of common building materials to soundproof floors, walls, and ceilings.  Simply adding Green Glue compound in between two layers of drywall gets a 52 STC with assemblies tested up to 73 STC!

Simply use 1 or 2 tubes of Green Glue per 4' x 8' sheet of drywall.  For projects that require 2 or more cases of Green Glue, use 5 Gallon pails to save money.

*Please Call for Best Pricing in NY & NJ!

Sound Transmission Class:

55 STC:  2 x 4 wall with Green Glue between 5/8" sheetrock on both sides (2 tubes/sheet)

The same wall without the Green Glue has only a 45 STC! (10 STC increase!)

Click here to go to our Green Glue Page

OWENS CORNING 703 RIGID FIBERGLASS ACOUSTICAL BOARD (3#)

Semi-Rigid fiberglass insulation in sheet form with a density of 3# pcf.  703 Fiberglass Board by Owens Corning is the staple of the acoustical absorption industry.  703 board is usually pinned to walls or ceilings of sound studios, control booths, or just noisey areas.  Once installed, 703 board can be covered with fabric.

NOISE REDUCTION COEFFICIENT (NRC):

1" THICK:   0.70 NRC
2" THICK:   1.00 NRC

OWENS CORNING 705 FIBERGLASS ACOUSTICAL BOARD (6#)

High Density Rigid fiberglass insulation in sheet form with a density of 6# pcf. 705 Fiberglass Board by Owens Corning is used in high abuse areas and where appearance is important. 705 board is the optimal acoustical insulation on walls that may get leaned against, kicked, or bumped into frequently.  Once installed, 705 board can be covered with fabric.

NOISE REDUCTION COEFFICIENT (NRC):

1" THICK:  0.65 NRC
2" THICK:  0.95 NRC

OWENS CORNING "SELECT SOUND" BLACK ACOUSTICAL BOARD

Select Sound provides excellent acoustical performance for multiplex theaters, sound studios and performing arts centers. Depending on specified thickness, board absorbs up to 100% of the sound striking its surface.  Black acoustic board Select Sound Black acoustic Select Sound helps provide the highest quality audio reproduction by reducing sound reverberation within spaces. Sound transfer from space to space is also noticeably reduced.

NOISE REDUCTION COEFFICIENT (NRC):

1" THICK:  0.70 NRC
2" THICK:  1.00 NRC

Click here to go to the Owens Corning Select Sound Page

METROFLEX MASS LOADED VINYL SOUND BARRIER

MetroFlex Mass Loaded Vinyl Barrier is a flexible high temperature fused vinyl that resists the passage of sound waves and reduces the transmission of airborne noise.  The standard MetroFlex Mass Loaded Vinyl Sound Barrier is 1/8" Thick (1 lb/sf) and has an STC rating of 26 which if installed properly will perform similar to a 2" x 4" wall with 5/8" drywall on each side of the wall.

MetroFlex Mass loaded vinyl can provide instant mass with damping to any location. In walls, ceilings, floors, on machinery, household appliances, around pipes, exterior fences, doors, as curtains to divide a room or over a window, and so on.

Click here to go to our Mass Loaded Vinyl Page

 MetroFlex Mass Loaded Vinyl

 MetroFlex Foil Faced Mass Loaded Vinyl

 MetroFlex Mass Loaded Vinyl with Fiberglass Decoupler/Absorber

SOUND BLOCKING ELECTRICAL OUTLET PUTTY PADS

PUTTY PADS: Metacualk Putty Pads are available as a 7.25" x 7.25" x 3/16" poly release faced pad for protection of recessed electrical boxes and as a through-penetration sealant. The pad is sized to fit a common 1-1/2" deep 4S electrical box.

To install remove release liner from one side of pad.  Align edge of pad to top of box and center pad. Adhere pad to top of box and bring pad down over the back of the box.  Adhering pad to all outer surfaces will create excess material at the corners. Pinch pleat material together and fold against sides of box or trim off as desired. Putty pad must be applied to a uniform depth of 3/16" (one layer of pad) over the exterior surface of box for both 1 and 2 hour applications. Optionally, additional putty may be packed into conduit fittings to prevent the transmission of smoke through the conduit system. Pads may also be used in through-penetrations. Strips of pad may be cut off and packed around penetrants. Pad strips may also be applied to penetrants in a mortar system to create a firestop as well as a cushion to absorb movement due to expansion and contraction or vibration.

Click Here to Go to Our Sound Blocking Putty Pads Page

ROXUL AFB ACOUSTICAL FIRE BATT MINERALWOOL BOARD

ROXUL products are mineral wool fibre insulations made from basalt rock and slag. This combination results in a noncombustible product with a melting point of approximately 2150°F (1177°C), which gives it excellent fire resistance properties. ROXUL mineral wool is a water repellent yet vapour permeable material.

ROXUL AFB (Acoustical Fire Batt) is a batt insulation product designed specifically for application in wall/floor systems where acoustical performance and fire resistance are the primary concerns. This noncombustible lightweight product has excellent acoustical dampening properties and is dimensionally stable which makes it ideal for friction fit into wall partitions and system applications from party walls to plant/manufacturing walls. The product is chemically inert which means that it will not promote corrosion. The AFB product comes in a number of thicknesses to meet the equirements of both retrofit and new construction applications.

*AFB is interchangeable with Safe N Sound and Comfort Batt.

Click here to go to our ROXUL AFB Product Page

ROXUL SAFE MINERALWOOL BOARD INSULATION

ROXUL products are mineral wool fibre insulations made from basalt rock and slag. This combination results in a noncombustible product with a melting point of approximately 2150°F (1177°C), which gives it excellent fire resistance properties. ROXUL mineral wool is a water repellent yet vapour permeable material.

ROXUL Safe product is a non-combustible, lightweight and water repellent semi-rigid insulation batt that provides fire stopping and acoustical insulation properties. Specifically engineered and produced as a fire stopping material for commercial, industrial and residential buildings, Roxul Safe can be used for the following applications:

- Perimeter gaps between concrete floor slabs and exterior wall systems,

- Around conduit pipe and duct openings through walls and floor slabs,

- Between fire walls and ceiling slabs.

This product has excellent fire performance properties, such as high melt temperature and low thermal conductivity which means the insulation acts as a shield against fire and temperature. In addition, Roxul products are subject to very little shrinkage in the critical phase of a fire, so the insulation layers remain in place to better prohibit the spread of flame. Roxul Safe is intended to be used in conjunction with a fire sealant to prevent the passage of fire and smoke.

MetroFlex Sound SealR Acoustic Sound Blocking Sealant

MetroFlex Sound SealR Acoustic Sound Blocking Sealant is a high quality latex-based sealing compound used as an essential component in construction assemblies for acheiving and maintaining the required STC rating as per IBC 1207.2 for air-borne sound.  Sound SealR is specially formulated for use with MetroFlex Mass Loaded Vinyl and possesses excellent adhesion to drywall, wood, metal, and concrete.  It remains permanently flexible and is both durable and long lasting.

Applications:

• Sealing the joints of Mass Loaded Vinyl
• Top and bottom runners prior to installation of drywall
• Outer edge perimeter joints of drywall
• Cut-outs and utility penetrations

Sound SealR is recommended for sealing all joints of mass loaded vinyl.   Apply bead of sealant at joints of two pieces of mass loaded vinyl if landing on the stud.  If joint falls within the wall cavity apply bead between the overlap layer as well as the seam.  Use of MetroFlex SealR Tape is also recommended to create the most air tight seal possible.

Meets ASTM-C834 /Tested to ASTM-E90 / Maintains 52 STC! / Complies with IBC Sections 1207.2, 710.6, 710.7, 402.4.1 / LEED Certified / Low V.O.C.

Click here to go to the MetroFlex Sound SealR Product Page

ACOUSTICAL SOUND FOAM TAPE

Acoustical Sound Foam Tape is a an elastomeric rubber/foam with adhesive backing that is 1/8" thick x 2" wide x 30ft long. Acoustical Sound Foam Tape is used for creating air-tight sound closures on windows, doors, and other openings. Acoustical Sound Foam Tape is alternatively used as a damping spacer on wood/steel studs prior to drywall/mlv installation. Acoustical Sound Foam Tape is also used as a vibration damper between two layers of drywall to provide the air-space needed for many STC rated wall/ceiling structures.

METROFLEX ACOUSTIC IMPALING CLIPS

Impaling clips are used to easily attach Acoustic Panels to walls. Each clip has 8 spikes that stick into the fiberglass and hold the panel in place. The dimensions of the clips are 2-1/8" x 1-1/2". The impaling clips are installed on the wall by either 1 drywall screw (not included) or attached with adhesive. 4-6 impaling clips are recommended per standard 2' x 4' panel making sure one impaling clip is placed in each corner. SOLD IN BOXES OF 24

SKU: 65IMPALING

METROFLEX BASS TRAP IMPALING BRACKETS

Bass Trap Impaling Brackets clips are used to easily attach Bass Trap Panels to corners of walls to cut off bass sound wave reverberation throughout the room.  For each Bass Trap, 4 Brackets must be used (2 Lefts and 2 Rights).  The brackets are precision cut on a 45 degree angle and can easily be screwed into the wall through die cut holes.  Sold in Sets of 2 (4 Lefts and 4 Rights).  SOLD IN BOXES OF 8

SKU: 65CORNER

METROFLEX PUSH DOWN IMPALER CLIPS

Push Down Impaler clips are used for fast and easy installation of acoustic panels to walls.  MetroFlex Push Down Impalers are made of galvanized steel and  contain two  angled prongs per clip (similar to the Bass Trap Impaling Brackets). The impaling clips are installed on the wall by either 1 drywall screw (not included) or attached with adhesive. 4  impaling clips are recommended per standard 2' x 4' panel making sure one impaling clip is placed in each corner. SOLD IN BOXES OF 24

SKU: 65PUSHDOWN

METROFLEX 2" STAND-OFF IMPALER BRACKETS

2" Stand-Off Impaler brackets are designed for installing Acoustic Panels to walls while providing a 2" air space between the back of the panel and the wall.  MetroFlex Stand-Off Brackets are made of galvanized steel and  contain four angled prongs per clip. The Stand-Off Brackets are installed on the wall by 2-4 drywall screw (not included). 4  impaler brackets are recommended per standard 2' x 4' panel making sure one stand-off impaler is placed in each corner. SOLD IN BOXES OF 8

SKU: 65STANDOFF

METROFLEX RESILIENT SOUND ISOLATION CLIPS

Sound Isolation Clips are used to decouple new drywall from the existing wall studs/ceiling joists.  The Resilient Sound Clips are screwed into the wood or metal studs and hold drywall furring channel in place.  The drywall sheets are then installed over the furring channel which limits the amount of contact between the new drywall and the existing wall/ceiling.  MetroFlex Reslient Sound Clips reduce the amount of sound vibration transmission through the wall/ceiling structure, creating a more sound resistant barrier. SOLD PER CLIP

SKU: 65RSIC

METROFLEX FLOATING FLOOR JOIST ISOLATORS

Floating Floor Joist Isolators are used to soften the connection between subflooring and the floor joists.  These 2" wide pieces of EPDM rubber are designed to clip onto the bottom of a  stud or joist by friction (no use of a fastener).  Rubber Joist Isolation clips are used primarily in floating floors of home theaters and sound studios to decouple the new floor from the subfloor. SOLD PER PIECE OR BOX OF 50

SKU: 65FLOAT

Click here to go to our SoundProof Guide
